Dishwashers
-
FDWU524
(Dishwashers - Top Controls)Viking 24-inch panel ready dishwasher. This dishwasher provides spotless dishes with three wash arms and a triple filtration system. Variable pressure wash adjusts water volume, pressure, and temperature according to load size and soil levels. Image shown with panel kit (Sold separately).
Product Features / Choose an option
LCD CONTROL PANEL
Allows for easy viewing of cycle/option selection and remaining wash time.
QUIET CLEAN™ PERFORMANCE PACKAGE
Three layers of insulation – bitumen, cotton and full side walls create one of the quietest dishwashers on the market.
REMOVABLE UPPER THIRD RACK
Accommodates large cutlery and utensils.
TURBO FAN DRY
Circulates air for efficient drying performance.
EXCLUSIVE SMART FULLSIZE™ RACK
Accommodates large cutlery and utensils.
THREE POSITION ADJUSTABLE UPPER RACK
Allows for loading of taller glasses in upper rack or larger pans in bottom rack.
IMPORTANT: Images may not reflect actual product.
| GENERAL | |
|---|---|
| Type | Built-In |
| Color | Panel Ready |
| Manufacturer Color | Panel Ready |
| Place Settings | 16 |
| Silence Rating | 42 dB |
| CYCLE INFORMATION | |
| Number of Cycles | 8 |
| Wash Cycles |
• Pots/Pans Plus • Glasscare • Auto • Combiclean • Regular Wash • Hourwash • Quick Wash (35 Min.) • Rinse/Hold |
| Options |
• Express Function • Sanitize Function • High Gloss • Intense Wash • Delay Start • FullSize™ Rack • Turbo Fan Dry • Quiet Clean™ Performance Package |
| FEATURES | |
| Technologies |
• FullSize™ Rack • Turbo Fan Dry • Quiet Clean™ Performance Package |
| Delay Start Information | 1-24 Hours |
| Delay Start | Yes |
| 3rd Rack System | Yes |
| Cutlery Tray | Yes |
| Filtration System | Yes |
| Silverware Basket | Yes |
| Additional Information |
• Variable Pressure Wash • Multi-Level Washing with Stainless Steel Bottom Spray Arm, Upper Spray Arm and top Nozzle Ensures Clean Dishes • Intensive Lower Rack Washing with Extra Spray Arm • Turbidity Sensor • Triple Filtration System • Flow-Through Water Heater • Top Rack is 3-Positon Adjustable • Telescopic Rail • Foldable Tines • Bottom Rack has Eight and top Rack has Six Split Foldable Tines with Variable Setting from Flat to Vertical • Sliding Cutlery Basket • LCD Screen with Remaining Time Indicator • Touch Button Direct Access Control • Cycle Indicator Light on Floor |
| ELECTRICAL INFORMATION | |
| Information |
• 120V • 60 Hz • 12 A |
| CERTIFICATIONS AND APPROVALS | |
| Energy Star Certified | Yes |
| NSF® Certified | Yes |
| ACCESSORIES | |
| Included | Drain Hose |
| Optional |
• Drain Hose High Loop • PDDP524 Viking Door Panel • PHK23 Professional Handle Kit |
| DIMENSIONS | |
| Class Width | 24" |
| Width | 23.54 inch(es) / 59.8 cm |
| Height (Min.) | 33.86 inch(es) / 86.0 cm |
| Depth (Without Handle) | 22.2 inch(es) / 56.4 cm |
| Additional Dimensions |
• Cutout Width: 24" (61.0 cm) • Cutout Height: 34" (86.4 cm) minimum to 36 1/4" (92.0 cm) maximum • Cutout Depth: 24" (61.0 cm) |
| SHIPPING DIMENSIONS | |
| Weight | 97 lb(s) / 44.0 kg |
| WARRANTY | |
| Warranty |
• One-Year Full – Complete Product • Ninety-Day Full – Cosmetic Parts Such as Glass, Painted Items, and Decorative Items • Lifetime Limited – Tank and Inner Door • Five-Year Limited – Electronic Controls, Racks, Motor/Pump Assemblies and Water Distribution System |
